Product Description
General features:
• digital multimedia receiver with AM/FM tuner (does not play discs)
• 9" hi-res capacitive touchscreen with adjustable vertical mounting positions and viewing angles
• high-resolution (1280x720 pixels) display
• fits single-DIN dash openings
• HD Radio tuner built-in
• Bluetooth hands-free calling and audio streaming (external microphone included)
Smartphone features (see Details for info on compatibility with specific smartphones and apps):
• Apple CarPlay compatible (wired and wireless)
• Android Auto compatible (wired and wireless)
• built-in iPod, iPhone, and iPad control
• playback and control of music files on compatible Android devices
• Pandora and Spotify control with iPhone and Android
• full Tidal integration with custom display (requires a wi-fi connection and Tidal smartphone app)
Audio/video features:
• plays MP3, WMA, AAC, APE, and FLAC music files (see Details tab for full capabilities)
• plays AVC, FLV, H,264, MP4, MPEG-4, and MOV video files
• plays lossless FLAC audio files up to 96kHz/24-bit
• 24-bit digital-to-analog converter (DAC)
• 13-band parametric equalizer (Basic or Advanced)
• 6-channel time correction
• high- and low-pass filters
• Bass Engine SQ
• Media Xpander HD
Expandability:
• works with SiriusXM SXV300 tuner—supports Tune Mix, Traffic & Weather Now, and Sports Flash features
• compatible with optional Halo wireless level controller
• compatible with optional 2-camera switcher
• compatible with optional HD dash cam with rear-view camera
• inputs: 2 rear USB ports; rear HDMI input; rear auxiliary input; 2 proprietary camera inputs (one composite video adapter is included for non-Alpine cameras)
• outputs: rear HDMI output; 6-channel preamp outputs (4-volt front, rear, subwoofer)
Other information:
• wired connection to parking brake required to access settings, video display, and other features on this receiver (the parking brake must be connected and set, released, and set again)
• built-in internal amp (16 watts RMS CTA-2006/50 peak x 4 channels)
• compatible with most factory steering wheel audio controls (adapter required)
• CTA-2006 compliant
• compatible with iDatalink Maestro
o retains factory features in a wide selection of vehicles
o displays engine performance data on touchscreen
