Product Description
:::::Specifications:::::
Number of channels : 2
Amplifier class : AB
Mono bridge mode : 4 ohm
Output power in 2 ohm : 2 x 100 Watt
Output power in 4 ohm : 2 x 70 Watt vid 0.1% THD
Damping factor : > 80
S/N ratio, A-weighted : > 95 dB
Frequency range : 10 Hz - 30 kHz
Input sensitivity : 0.25 - 5 Volt
Input impedance : 22k ohm
Input impedance, high level : 47 ohm
High pass filter : 50 - 500 Hz
Low pass filter : 50 - 500 Hz
Grand bass filter : Bass EQ +6dB / +12 dB @ 50 Hz
Low level output : No
High level input with auto start : Yes
Power consumption (idle) : 0.4 A
Power consumption (max) : 25 A
Rec. power cable : 16 sq mm ( 5 AWG)
Fuses : 1 x 25 A
Dimension (W x D x H) : 189 x 210 x 46 mm ( 7.44" x 8.26" x 1.81")
Weight : 2 kg
Other Details
Warranty Information
1 Year Warranty
