Product Description
:::::Specifications:::::
Number of channels : 4
Amplifier class : AB
Peak power : 4 x 100Watt
Output power in 2 ohm : 4 x 100 Watt
Output power in 4 ohm : 4 x 70 Watt
Mono bridge mode : 4 ohm 2 x 200 Watt
Damping factor : >80
S/N ratio, A-weighted : >90 dB
Frequency range : 10 Hz - 30 kHz
Input sensitivity : 0,25 - 5 Volt
Input impedance : 22 kohm
Input impedance, high level : 47 ohm
High level input with auto start : Yes
Remote bass level control : No
Low level output : No
Remote phase shift control : No
Grand bass filter : Bass EQ @ 50 Hz: +6db / +12 dB
Power consumption (idle) : 0,5 A
Power consumption (max) : 50 A
Rec. power cable : 16 sq mm ( 5 AWG)
Fuses : 2 x 25 A
Dimension (W x D x H) : 189 x 322 x 46 mm (7.44" x 12.67" x 1.81")
Weight : 3 kg
Other Details
Warranty Information
1 Year Warranty
