Product information "ETON Graphite 10-4 subwoofer chassis 25cm (10") 500 watts, 2 x 4 ohms"
The very special subwoofer series for the 40th ETON anniversary: GRAPHIT - quality, top-class materials and know-how "Made in Germany"
The innovative 25 cm (10") high-end double voice coil subwoofer GRAPHIT 10- 4, impedance 2 x 4 ohms, is built for discerning music lovers who want precise bass performance and audiophile sound in their vehicle: impressive thanks to its extremely impulsive and powerful sound image, as well as dry, contoured bass runs with incredible dynamic fireworks - a subwoofer for sound -Gourmets!
The GRAPHIT 10-4 offers ETON-typical refinements and innovative detailed solutions: This includes the specially developed die-cast aluminum basket, which thanks to special ventilation openings guarantees efficient cooling of the oscillating unit.
The extremely strong ferrite magnet and the heavy-duty large double voice coil provides the powerful drive
CNC-machined pole plates with a large core bore and additional ventilation openings enable the necessary vibration depth and support cooling.
The newly developed, extremely torsion-resistant carbon fleece sandwich membrane, in combination with the highly resilient Long-throw surround for an impulse-accurate music reproduction, for razor-sharp precision and a dynamic that was and is so rare.
The highly stable, coated aluminum dust cap has a heat-dissipating effect due to its special coupling and thus increases the thermal resilience.
Newly designed connection terminals with screw connections guarantee a secure connection.
The very special subwoofer series for the 40th ETON anniversary: GRAPHIT - pure quality, top-class materials and know-how made in Germany.
The innovative 25 cm ( 10") high-end double voice coil subwoofer GRAPHIT 10-4, impedance 2 x 4 ohms, is built for demanding music lovers who want precise power and audiophile sound in their vehicle:
Extremely fast, dynamic punches, rock-hard stops and impressive deep bass passages - the GRAPHIT 10-4 is a subwoofer in a class of its own!
The extremely strong ferrite magnet and the resilient, large double voice coil provide the powerful drive.
The newly developed, extremely torsion-resistant carbon fleece sandwich membrane ensures in combination with the heavy-duty long-throw surround for an impulse-true music reproduction, for razor-sharp precision and a dynamic that was and is so rare.
Included:
1x subwoofer 25cm
Instruction manual
Technical data GRAPHIT 10-4
Max. Load capacity: 2 x 500 watts
Rated power handling: 2 x 300 watts RMS
Nominal impedance: 2 x 4 ohms
Sensitivity: 85 dB
Outer Ø: 265 mm
Cut-Ø: 235 mm
Installation depth: 124.5 mm
KEY FEATURES
Specially developed die-cast aluminum basket with special ventilation
Extremely strong ferrite magnet, CNC-machined pole plates with large core bore and additional ventilation openings, large double voice coil
Carbon fleece sandwich cone
