Product Description
:::::Specifications:::::
Number of channels : 1
Amplifier class : D
Output power in 1 ohm : 550 W RMS
Output power in 2 ohm : 370 W RMS
Output power in 4 ohm : 200 W RMS
Damping factor : > 140
S/N ratio, A-weighted : > 92 dB
Frequency range : 10 Hz - 2500 Hz
Low level output : No
Input sensitivity : 1 - 4 V
Input impedance : 22 kohm
Input impedance, high level : 45 ohm
High pass filter : Subsonic 30 Hz, ON/OFF
Low pass filter : 35 - 250 Hz, 12 or 24 dB slope
Grand bass filter : Bass boost 0- +6dB variable
Phase control for subwoofers : 0 or 180 degrees switch
High level input with auto start : Yes
Remote phase shift control : No
Power consumption (idle) : 0,8 A
Remote bass level control : Yes
Power consumption (max) : 80 A
Integrated fan : Yes
Rec. power cable : 2AWG / 33 mm2
Fuses : Use external fuse 60 A
Dimension (W x D x H) : 129 x 304 x 51 mm / 5,07 x 11,96 x 2"
Weight : 2,4 kg / 5,3 lb
