Product Description
:::::Specifications:::::
Woofer size : 16,5 cm (6,5")
Tweeter : RC28, 28 mm (1,25") silk dome tweeter with copper rings
Power handling capacity : 100 W RMS / 150 W max / 300 W peak power
Impedance : 4 ohm
Frequency range : 50 - 25 000 Hz
Sensitivity : 90 dB (1W/1m)
Crossover : Filter box with 6/12 dB slope (LP/HP)
Crossover point (Hz) : 4500 Hz
Size of filter box : 145 x 85 x 45 mm ( 5,71 x 3,35 x 1,77")
Outer diameter of woofer : 165 mm (6,5")
Cone material : Black anodized aluminium cone
Magnet size : 110 mm (4,33")
Mounting depth : 75 mm ( 3")
Mounting hole : 145 mm (5,7")
T/S parameters :
single V/C
Fs 58,7 Hz Re 2,3 Ohm Qms 3,5
Vas 9,65 liter Vas 0,34 Cuft Qes 0,76
Qts 0,62 Sd 147 cm² BL 5,06
Other Details
Warranty Information
1 Year Warranty
